Model
|
LED Power
|
Size
|
Housing N.W.
|
Housing Set N.W.
|
Chips QTY
|
Battery Box Size
|
|---|---|---|---|---|---|---|
|
CET-106
|
50W
|
186 x 158 x 52 mm
|
210 g
|
390 g
|
50 LED
|
158 x 130 x 45 mm
|
|
CET-106
|
120W
|
222 x 171 x 52 mm
|
300 g
|
570 g
|
120 LED
|
194 x 143 x 45 mm
|
|
CET-106
|
150W
|
278 x 219 x 52 mm
|
390 g
|
840 g
|
150 LED
|
250 x 191 x 45 mm
|
|
CET-106
|
200W
|
351 x 246 x 60 mm
|
660 g
|
1050 g
|
200 LED
|
323 x 218 x 53 mm
|
Material applies to all wattages: Die-cast aluminum + PC lens
2. Recommended Solar Solution
|
LED Power
|
Battery
|
Solar Panel
|
Real Power
|
Working Time
|
|---|---|---|---|---|
|
50W
|
3 PCS 15AH
|
20W
|
6–8W
|
18–20 H
|
|
120W
|
4 PCS 20AH
|
25W
|
10–12W
|
18–20 H
|
|
150W
|
5 PCS 25AH
|
30W
|
12–15W
|
18–20 H
|
|
200W
|
6 PCS 30AH
|
35W
|
15–18W
|
18–20 H
|
