Using adc12 die-casting aluminum, integrated molding process withhigh heatdissipation rate.
Super new lithium iron phosphare A battery.
High conversion rate monocrystalline silicon photovoltaic panel.
60°/90° /120°/75°*150°/T2M/T3M for different application.
Control mode: lighting control (ight on when light, light off when daytime)
IP Rating：IP66
Warranty：5Yrs
| 产品型号 Model |
电池容量 Battery Capacity |
光伏板 Solar Panel |
流明 Lumen |
灯珠数 LED QTY |
安装高度 Installation height |
灯体尺寸(mm) LampSze(mm) |
光伏板尺寸(mm) Solar Panel Size(mm) |
包装尺寸 ( cm ) Packing Sze(cm) |
| SYSC-SL006-50 | 12.8V 25AH | 18V 120W | 10000LM | 240PCS | 8M | 700*258*110 | 670*1200*1 | 131*78*34 |
| SYSC-SL006-80 | 12.8V 50AH | 18V 180W | 14000LM | 240PCS | 8M | 700*258*110 | 680*1470*1 | 155*78*34 |
| SYSC-SL006-120 | 12.8V 80AH | 18V 150W*2 | 16000LM | 240PCS | 10M | 700*258*110 | 670*1210*2 | 131*78*39 |
| SYSC-SL006-160 | 25.6V 50AH | 36V 180W*2 | 20000LM | 240PCS | 10M | 700*258*110 | 680*1470*2 | 155*78*39 |
